BRILLARE A

LED laser blade lights provide discreet, glare-free lighting with precise beam control, seamlessly integrated into modern ceilings for high-end architectural spaces.
Features
  • Provide precise and glare-free illumination with superior visual comfort
  • Deliver ultra-discreet and high-performance lighting with a minimalist aesthetic
  • Using a linear array of micro-optics recessed into the ceiling
  • Ideal for premium architectural spaces
Applications
  • Boutiques
  • Hotels
  • Galleries
  • Modern residences
Additional Info

Input voltage: 85-265V

Led: SMD (Bridgelux/Osram)

Bean angle distribution diagram: 12° | 24° | 36° | 60°

Technical Specifications

Body Material: Die cast aluminum with tempered glass diffuser

Type: Surface mounted Laser Blade Light

Finishes: Black | White | Gray

Reflector: Black | White | Silver | Gold

IP Rating: IP65

Beam Angle: 12° | 24° | 36° | 60°

CRI: ≥90

Color Temperature: 2700K | 3000K | 4000K | 5000K | 6000K

Lifespan: 35,000hrs | 50,000hrs

Working Temperature: -15°C ~ +55°C

Variants (Models Table)
MODEL WATT LUMEN LED SIZE CUT-OUT
200610-A 5*2W 1200lm SMD ø170*55*H85mm
200610-B 5*2W 1200lm SMD ø160*58*H46mm ø155*50mm
200610-C 5*2W 1200lm SMD ø170*55*H85mm
